S25 Continuous Mixing Double-Arm Resin Sand Mixer Machine for Foundry Industries Easy to Operate Core Components Bearing Pump

S25 Continuous Mixing Double-Arm Resin Sand Mixer Machine for Foundry Industries Easy to Operate Core Components Bearing Pump

Quantity:
Availability:





Inquire Add to Basket

Product Description

Product Description

Resin sand sand mixer can be divided into: single arm resin sand mixer and double arms resin sand mixer .
Double Arms resin sand mixer's most widely used, its characteristic is can be made up of free secondary rotary stirring cage, the first level is conveying stirred cage, conveying the original sand .The second level is high speed mixed sand stirring cage .Liquid resin and curing agent are in the second stage injection,first of all injection curing agent , a period of time and then sprayed into the resin .

Purpose:

It is widely used in the mixing of self hardening sand for large cast iron, cast steel and other castings. The machine is a elevating sand mixer, which is easy to operate and has fullfunctions . It can be adjusted and selected according to diferentcharacteristics of resin sand technology. The machine is mainly composed of sand mixer,traveling mechanism, sand hopper, electriccontrolsystem,air control system, dust removal system, etc.

Characteristics:
1. Supply system of the adhesive adopt advanced wheel pump, diaphragm pump and liquid detector, measurement accuracy.

2. Short mix time, no less sand from end to end, Double arms rotating flexible, large area of operation.

3. Open type sand mulling mix cage arm, easy clean and adjust leaf and convenient maintenance.

4. To set advanced fluidization boiling, the powder content of sand is further reduced and the quantity of adhesive is substantially reduced and improve the quality of the sand mixture and get good economic benefits.

5. The electrical devices adopt PLC control system, abundant confinement and protection. Simulation-screen display, stable and reliable working, to achieve automatic production.

Product Application

It is widely used in the mixing of self hardening sand for large cast ron, cast steel and other castings.

It can be adjusted and selected according to diferentcharacteristics of resin sand technology.

Product Features

The binder supply system adopts advanced gear pump, diaphragm pump, liquid detector and accurate measurement. Short mixing time,less head and tail sand. Flexible rotation of both arms, large operation area.

lt adopts split type sand mixing tank with stainless steelinner lining for easy cleaning and maintenance;sand mixing blade is inlaid withhard alloy cutter head for long service life.

The machine head is equipped with head and tail sand control device and odor and dust removal device.

This series of double arm continuous resin sand mixer is mainly used for mixing resin self hardening sand and sodium silicate sand.

The fully open mixing cage wall is convenient for blade cleaning or adjustment and convenient for blade cleaning or adjustment and O convenient for operation and maintenance. The electric appliance is controlled by PLC, with sufficient restriction and protection, analog screen display, stable and reliable operation, and automatic production.controlled by frequency conversion, which can realize fast and slow action; the safety systemis equipped with balance weight, track cleaning and audible and visual alarm devices.

Electric Control System

Model:Automatic or manual type
Control Unit: PLC .
P L C: Siemens, Omron or famous reliable brand in China for your choice.
Emergency Stop: on main control panel and rollers conveyors.
Power Indicator: available on control panel .

Advantages of resin sand processing equipment

Sand abrasion groove plate and the blade have less abrasion and the engine temperature is lower and mixing sand is uniform, when sand is being mixed.

Technical Parameter

item	value
weight (kg)	7000
warranty	1 years
place of origin	China
brand name	Qingdao Haoyang Casting Machinery Co., Ltd.
video outgoing-inspection	Provided
machinery test report	Provided
core components	PLC, motor
material	Metal / Coil
producivity(t/h)	3-5/8-10/10-12/12-15/18-25/25-30
key selling points	Easy to Operate
After-sales Service Provided	Engineers available to service machinery overseas
Color	Customers Requirement
Application	Steel plate, beam, pipe, profile, channels etc
Frequency controller	Included

Detail technical data,pls confirm with supplier.

The machine is mainly composed of sand mixer,traveling mechanism, sand hopper, electriccontrolsystem,air control system, dust removal system, etc
